Helical Gears
Atlas Global supports gearbox manufacturers with internal and external helical gears built to your specifications for high-volume programs. Our global sourcing approach is reinforced by domestic inspection and documentation to support consistent assembly.
Helical gears can be produced through hobbing, shaping, shaving, and grinding processes, with capacities up to 15" OD and 2–64 DP. We produce and source helical gears in annealed, hardened, and stainless steels, plus other ferrous and nonferrous materials, supported by in-house ISO 9001 inspection and complete documentation.
Helical gears can be produced through hobbing, shaping, shaving, and grinding processes, with capacities up to 15" OD and 2–64 DP. We produce and source helical gears in annealed, hardened, and stainless steels, plus other ferrous and nonferrous materials, supported by in-house ISO 9001 inspection and complete documentation.
Specifications
MAX DIAMETER
15” OD
MAX FACE WIDTH
8.75"
PitcH Range
2 - 64 DP
Pressure Angle
14.5 - 45°
Custom Helical Gear Samples
teeth
6
Pressure Angle
28°
Helix ANGLE
28°
Length
3.000"
DIAMETER
1.5"
DIAMETRAL PITCH
24-48 DP
Pressure Angle
28°
Feature
Right Hand
DIAMETER
8"
Length
2"
Feature
Flat Root Side Fit
Feature
Keyway Driven
teeth
75
Pressure Angle
20°
Helix ANGLE
30°
Feature
Ground Gear
Gear quality has been our priority since our founding in 1992, because your equipment depends on accuracy, repeatability, and long-term reliability.
From prototypes to AGMA 15 gears, each part is verified with in-house ISO 9001 inspection.
Explore Other Gears
Discuss your gear prints with an engineer.
Schedule a call today to get started on a gearbox component manufacturing quote. Send prints or models, target quantities, material requirements, and any inspection or documentation needs.
Get a Quote
